Technische Dokumentation
After the 3D modelling for our watch movement project is now almost complete, we will produce a series of technical drawings and supporting documentation to facilitate a detailed request for quotation from the manufacturers, ensuring a smooth process in our industrial design efforts.
For our watch Project with Imperia Anteo 2800, here is the exact Set up for the bringing together the ANTEO SPORT SERIES - The Rear Entry mechanism
- Material Mastery: Forged from aerospace-grade 316L Stainless Steel with custom Gold PVD surface hardening.
- Micro-Tolerances: Machined to an exact 42.00 ±0.05 mm diameter and 22.00 ±0.1 mm lug width profile.
- Active Resilience: Rated for 5ATM water resistance, encasing the complex automatic movement inside a slimline silhouette.
Imperia Anteo 2800 | Spec Sheet
Ref: IMPA-2800-DWG-001Built for individual collectors who inspect the blueprints for themselves.
- Chassis: Solid 316L Stainless Steel. 42.00mm diameter. ±0.05mm tolerances.
- Profile: 6.00mm sidewall depth (12.50mm total depth).
- Crown: 6.00mm diameter. 0.3mm pitch knurling.
- Lugs: 22.00mm spacing. 1.80mm spring-bar channel.
- Se
For our watch movement project by Imperia Germany, the motion works of their watch movement developed by us.
Motion works for the watch winding system
Detailed overview of if the watch rotor mechanics system.
For our watch movement project by Imperia Germany, the motion works of their watch movement developed by us.
Oscilating Movement Rotor. Specially designed Anchor framed Rotor by UBUO DESIGN.
